The TTI TCB-950 CB radio is the latest model in the TTI CB range with an integral front speaker developed to give outstanding performance with clear and crisp audio. Out of the box it has the option for either a traditional bracket mount or it can be mounted in a DIN sized hole (with the optional DIN mount TDP-5000).
The TCB-900 also has a very short back making it easy to fit in apertures of limited size and also includes a three colour selectable LCD display.
Features:
4W Output power
Front mounted speaker
Short Body
DIN size (with the optional DIN mount TDP-5000)
12/24V input
Multiple bands for usage in most EU countries
AM/FM Operation (subject to country regulation)
DSS (Dynamic Squelch System)
Multi-Colour Backlighting
Emergency Channel (9/19) / Keypad Lock function button
Microphone Gain
Attenuation
Scan function
Speaker Mute
Menu Mode (Microphone Gain, Call tone, Beep Tone On/Off, TOT, Backlight Dimmer)
Dimension (W x H x L) : 170 x 51 x 94mm
Technical specifications:
Channel: 40
Frequency Range: 26.965 MHz - 27.99125 MHz (26.965 MHz - 27.405 MHz (CEPT),
Operating Mode: F3E (FM), A3E (AM)
Frequency Control: PLL Synthesizer
Frequency Tolerance: 0.002%
Operating Temperature Range: -10 to 55 Degrees Celsius
Microphone: 6 Pin plug in type
Antenna Connector: SO239 Type
Weight: 978.5g
Power Output: Duty cycle 10% 4Watts @13.8V DC
Modulation: AM (85% to 95%), FM (1.8KHz +- 0.2KHz)
Frequency Response: 300Hz to 3000Hz
Output Impedance: 50 ohms, Unbalanced
Harmonic Suppression: Less than -54dBm
Current Drain: AM Full Mod. 1.6A Max
Receiving system: Dual conversion super-heterodyne
IF Frequencies: Double Conversion 1st 10.695MHz / 2nd 455KHz
Sensitivity: 0.7uV for 10dB (S+N)/N in AM, 0.5uV for 20dB SINAD in FM mode
Audio Output Power: 4.0W @ 8 ohm
Audio Distortion: Less then 8% @ 1KHz
Image Rejection: More than 60dB
Adjacent Channel Rejection: More than 60dB
Conducted Spurious: Less than -57 dBm
Frequency Response: 300 to 2500Hz
Built-in Speaker: 8 ohms, round
Squelch: Adjustable; Threshold less than 1 microvolt, DSS; Less than 2 microvolt
|
