Alinco DR-438H

• Frequency range: 430.000 - 439.9975 MHz
• Output power selectable 45W/25W/10W
• PC programmable 200ch
• Alphanumeric name tags
• Voice Compander (Reduce Noise & enhance audio clarity)
• 2-Tone, 5-Tone, 50 CTCSS, 114DCS, 4 Toneburst tones and DTMF/ANI decode
• Radio stun/kill/revive functions to protect your communication security
• Large, bright LCD and easy to operate backlit keys
• Multifunction, backlit microphone enables direct frequency entry & more from keypads
• Various scan modes, Key lock, Wide/Narrow operation
• Inversion scramble feature
• Channel Spacing
  25KHz (Wide mode)
  20KHz (Middle mode)
  12.5KHz (Narrow mode)
• Channel step
  2.5KHz,5KHz, 6.25KHz, 8.33KHz, 10KHz,
  12.5KHz, 15KHz, 20KHz, 25KHz, 30KHz, 50KHz
• Operating Voltage 13.8V DC ±15%
• Squelch Carrier/CTCSS/DCS/5Tone/2Tone/DTMF
• Frequency Stability ±2.5ppm
• Operating Temperature -20~+60
• Dimensions 145 (W) x 47 (H) x 190 (L)mm approx.
• Weight approx. 1.23kg

Package contents:

1 x Alinco DR-438 H Transceiver

1 x Microphone

1 x Mounting Bracket with Fixing Screws

1 x Power Cord

1 x User Manual in English
