Kenmerken
Tunable from 27 to 28.5 MHz
Protection from static discharges DC-Ground
17/7 PH tapered stainless steel whip
90° inclination and adjustable whip, detachable for car-wash
Suitable for magnetic mount
UPDATE: new glazed chromed surface, blue plastic parts
Technische specificaties
Type: base loaded
Frequency range: 27...28.5 MHz
Impedance: 50 Ω
Polarization: linear vertical
Bandwidth @ SWR ≤ 2:
TURBO 2000 PL: ≥ 1100 KHz (100 channel)
SWR @ res. freq.: ≤ 1.2
Max. power:
200 Watts (CW) continuous
1000 Watts (CW) short time
Mounting: UHF-male (PL 259)
Mechanische specificaties
Materials: Brass, Copper, Nylon, Stainless Steel
Height (approx.): 1450 mm
Weight (approx.): 550 gr
Dit is de antenne compleet met kabel en voet.
Deze antenne kan alleen opgehaald worden in onze winkel.
Wordt dus niet verstuurd i.v.m. zijn lengte van 1,5 meter.
|
