SS460S Hall-effect switch
Artikelcode:	12
Prijs:	EUR 1.30
Verzendkosten:	EUR 0.00
Voorraad:	in voorraad
Omschrijving:	Industriele kwaliteit Fabrikant: Honeywell 3 - 24 volt. 20mA The SS460S is a high-sensitivity bipolar latching digital hall-effect Sensor IC, small, sensitive and versatile devices that are operated by the magnetic field from a permanent magnet or an electromagnet. This is designed to respond to alternating North and South poles. SS460S is turned ON by a South pole. The high-sensitivity bipolar latching digital hall-effect sensor IC offers reliable switching points with a high magnetic sensitivity of 30G typical (55G maximum). This sensor IC does not use chopper stabilization on the Hall element, providing a clean output signal and a faster latch response time when compared to competitive high sensitivity Hall-effect bipolar latching sensor ICs which do use chopper stabilization. - Fastest response time, provides more efficiency in commutating a brushless DC motor - No chopper stabilization, results in a clean output signal - High sensitivity - Bipolar latching magnetic - Wide operating voltage range, allows for potential use in a wide range of applications - Built-in reverse voltage, enhances the protection of the sensor and the circuits - Durable design, allows operation up to 150°C (302°F) Toepassingen Industrial, Commercial, Motor Drive & Control, Sensing & Instrumentation, Metering, Robotics, Logistics, Medical Waarschuwingen ESD sensitive device, take proper precaution while handling the device. Voor datasheet klik op deze link
Verzendkosten:	binnenland: EUR 6.95 buitenland: EUR 25.00
